29117-1
4x80A 4X80 + 2X16 K SerisiCoresMulti-contact Plugs and Sockets

29117 – Fiş

Product Code
29117
Number of Contacts
4P+2P+E
Cinsi
Plug
Product Type
Çekirdek
Plug
Product Code 29117
Number of Contacts 4P+2P+E
Cinsi Plug
Product Type Çekirdek
Voltage Energy:830 V, Signal: 400 V
Amps 80 A , Signal: 16 A
Connection Type Screw Connection
Suitable Body Type 16B
Kaynak URL https://metecon.com.tr/tr/çekirdek-61-29117.aspx
Connection Method Screw connection
Tip Plug
Series K Serisi
Suitable Body Type 16B
Number of Contacts 4P+2P+E
Conductor Cross Section 80 A : 1.5 ... 16 mm² | 16 A : 0.5 ... 2.5 mm²
Cable Entry Back
Current 80 A , Sinyal: 16 A
Nominal Gerilim İletken-Toprak -
Nominal Gerilim İletken-İletken 830 V, Sinyal: 400 V
Nominal Impulse Voltage 8kV Sinyal: 6kV
UL Uyarınca Nominal Gerilim 80 A : 600 V [UL] /300 V [ CSA] | 16A :600 V [UL] /600 V [CSA]
Yalıtım Direnci ≥1010Ω
Contact Resistance ≤1mΩ
Sıcaklık Sınırlaması -40 ... +125 °C
Sıyırma Uzunluğu 14 mm, Signal: 7 mm
Sıkma Torku 1.2 | 2 | 3 | 3 | 3 | 3
Eşleşme Döngüsü ≥500
AWG 1.5 | 2.5 | 4 | 6 | 10| 16
Kirlilik Derecesi 3
Hammadde (Çekirdek) PBT
Renk (Çekirdek) Gray - RAL 7044
Hammadde (Kontak) Brass (Silver plated)
UL 94 Uyarınca Malzeme Yanıcılık Sınıfı V-0
RoHS İstisna ile uyumlu
Uygulama Standartları IEC 61984 / UL 1977
Certificates UL | cUL | TSE
Number of Boxes 30
Net Ağırlık 65
Menşei Ülke Turkey
GTİP Kodu 8536.69.90.00.18
EAN13 Kodu 8699011016142
Document Not Found.
Certificate Not Found.
403431S-1
4x80A4X80 + 2X16K Serisi
403431S - UZATMA PRİZİ METAL MANDAL CONTALI-IP65
Product Code
403431S
Product Type
UZATMA PRİZİ METAL MANDAL CONTALI-IP65
Cinsi
Socket
Number of Contacts
4x80A + 2x16A (4P+2P+E)
403422-1
4x80A4X80 + 2X16K Serisi
403422 - UZATMA PRİZİ-IP65
Product Code
403422
Product Type
UZATMA PRİZİ-IP65
Cinsi
Socket
Number of Contacts
4x80A + 2x16A (4P+2P+E)
403430-1
4x80A4X80 + 2X16K Serisi
403430 - UZATMA FİŞİ-IP65
Product Code
403430
Product Type
UZATMA FİŞİ-IP65
Cinsi
Plug
Number of Contacts
4x80A + 2x16A (4P+2P+E)
403429-1
4x80A4X80 + 2X16K Serisi
403429 - UZATMA PRİZİ-IP65
Product Code
403429
Product Type
UZATMA PRİZİ-IP65
Cinsi
Socket
Number of Contacts
4x80A + 2x16A (4P+2P+E)
403753S-1
4x80A4X80 + 2X16K Serisi
403753S - DUVAR FİŞİ TEK METAL MANDAL MENTEŞELİ KAPAK-IP65
Product Code
403753S
Product Type
DUVAR FİŞİ TEK METAL MANDAL MENTEŞELİ KAPAK-IP65
Cinsi
Plug
Number of Contacts
4x80A (4P+E)
403755S-1
4x80A4X80 + 2X16K Serisi
403755S - DUVAR FİŞİ TEK METAL MANDAL MENTEŞELİ KAPAK-IP65
Product Code
403755S
Product Type
DUVAR FİŞİ TEK METAL MANDAL MENTEŞELİ KAPAK-IP65
Cinsi
Plug
Number of Contacts
4x80A (4P+E)
403423-1
4x80A4X80 + 2X16K Serisi
403423 - UZATMA FİŞİ-IP65
Product Code
403423
Product Type
UZATMA FİŞİ-IP65
Cinsi
Plug
Number of Contacts
4x80A + 2x16A (4P+2P+E)
403754S-1
4x80A4X80 + 2X16K Serisi
403754S - DUVAR PRİZİ TEK METAL MANDAL MENTEŞELİ KAPAK-IP65
Product Code
403754S
Product Type
DUVAR PRİZİ TEK METAL MANDAL MENTEŞELİ KAPAK-IP65
Cinsi
Socket
Number of Contacts
4x80A (4P+E)
403752S-1
4x80A4X80 + 2X16K Serisi
403752S - DUVAR PRİZİ TEK METAL MANDAL MENTEŞELİ KAPAK-IP65
Product Code
403752S
Product Type
DUVAR PRİZİ TEK METAL MANDAL MENTEŞELİ KAPAK-IP65
Cinsi
Socket
Number of Contacts
4x80A (4P+E)
403750S-1
4x80A4X80 + 2X16K Serisi
403750S - MAKİNE PRİZİ TEK METAL MANDAL MENTEŞELİ KAPAK-IP65
Product Code
403750S
Product Type
MAKİNE PRİZİ TEK METAL MANDAL MENTEŞELİ KAPAK-IP65
Cinsi
Socket
Number of Contacts
4x80A (4P+E)
